Adapting panels for uneven walls

Check the space thoroughly with your spirit level. If parts of the wall or floor are uneven, then you’ll need to cut the filler panels to match the wall’s shape using the following method. If everything is level, skip ahead to Step Two.

If you have any uneven walls, then you’ll need to make a template to cut to. You’ll need a tape measure, compass, pencil and thick cardboard for template material. • Cut the cardboard to the same height of the cabinet. • Position it to the place where the filler panel is needed. • Place the compass against the wall. • Keep the compass horizontal and level, and follow the line of the wall, tracing the shape of the wall onto the cardboard. • Measure the distance from the farthest point of the wall to the cabinet and mark it. • Cut the template along each pencilled line, ensure that it fits, then trace the shape of the cardbord onto the filler panel. • Proceed to Step Three.

Measuring the gap for even walls

If the walls are level, simply measure the distance from the wall to the back of the cabinet, mark this distance on the top and bottom of the filler panel, then draw a line between the two marks.

Cutting the panels

Cutting the panels You should use a circular saw for this task, following the recommended method.

Using a handsaw

Cut along the marked line with the face side of the panel up.

Using a jigsaw

Mark both sides of the panel. To avoid chipping, apply masking tape to the marking on the face side. Cut the panel with the face side down.

Installing the filler panels

Place the filler panel into the space with the cut edge against the wall. Make sure the panel stays securely in place while you attach it to the cabinet. After pre-drilling holes, attach the panel with screws from the inside of the cabinet. Repeat the process with any other filler panels you need to install.
